Essex Magnet Wire 21 AWG Gauge Enameled 10LBS

Model # :  AWG21-200C-11

Price Range: $102.99

Enter Quantity:

Add to Wishlist

Essex Magnet Wire  21 AWG Gauge Enameled 10LBS Average Shipping Weight High Temp Class 200C Heavy Build

Premium quality Essex magnet wire in original factory spool

High temperature Class: 200°C (392°F)

In original factory packaging. Made and spooled by Essex.

UL recognized Class 200 magnet wire

Essex is the world’s largest producer of magnet wire

Why should you buy original Essex factory magnet wire spool  ?

Original factory spool is professionally wound by the magnet wire manufacturer. Unprofessional re-spooling can easily damage or scrape the insulation film, damaged magnet wire can not be used for coil winding. Poorly re-spooled wires can ultimately reduce coil winding quality.

Dimensional Data

Nominal Diameter: 0.031 inch



Nominal OHMS/LB. -20 Celsius: 5.054

Feet/LB: 395.9

Magnet Wire Technical Specifications:

Conforms to MW-35C, UL recognized Class 200

High temperature Class: 200°C (392°F)

Magnet Wire AWG size: 21 AWG, round

Insulation type: modified polyester basecoat and an improved polyamideimide topcoat

Insulation build: heavy build, more durable than single build

Approximate Shipping Weight Range: 10 lbs to 13 lbs

Magnet Wire Spool Weight: 9 to 12 lbs

Magnet Wire Applications:

Wind Generators
Fractional and Integral HP Motors
Hermetic Motors
DC Motors
Power Tools
Automotive Alternators and Generators
All Dry Type Transformers, Class 105 through 200
Electronics, All Types of Coils, Class 105 Through 200
Arts & Crafts

This type of Essex magnet wire is the standard of comparison for magnet wire performance in virtually every severe and heavy duty application. The combination of a modified polyester basecoat and an improved polyamideimide topcoat results in an insulation system with outstanding physical toughness, excellent dielectric properties, and superior chemical resistance to most common solvents and refrigerants.
Windability of this type of Essex magnet wire, verified by years of experience on virtually every type of winder, has always been excellent. Improvements in the topcoat have resulted in a product that is even more superior with regard to high slot fill and insertability.

Note: Shipping Weight for each spool varies, it normally ranges from 10 to 13 lbs

Contact us for Essex magnet wire wholesale discount

Current Reviews: 2Write a review on this product!
by John Smith
Date Added: Tuesday 31 August, 2010
Wire was exactly as advertised online. Shipped the next day
after ordering. No kinks and pulled off spool nice and smooth. I used it to wire a large tesla coil secondary. No complaints!

Rating: 5 of 5 Stars [5 of 5 Stars]
by Les Kraut
Date Added: Thursday 15 September, 2011
Very fast shipping, excellent service, great product!
Thanks!

Rating: 5 of 5 Stars [5 of 5 Stars]
