Product Details
Every wind turbine is made differently. WindMax V10 Wind Turbines are proven systems deployed worldwide with good performance track records. WindMax V10 Wind Turbines feature low start-up speed, good performance at low to medium wind speed. WindMax V10 Wind turbines are made professionally in ISO certified factory, they are CE certified and passed factory quality inspections. Recommended working wind speed range is from 5 mph to 30 mph. Overspeed control mechanism is combination of mechanical furling and controller electrical braking.
WindMax V10 Wind turbines are neighborhood friendly with low noise level. Please call us for noise measurements.
Warranty is available upon request, please contact us for details.
This wind turbine qualifies for a cash rebate from state of California, the manufacturer is Yangzhou Shenzhou Wind-driven Generator Co., Ltd. You may find similar-looking wind turbines on the market, please verify if they have the authentic factory quality even if you are not in California and are qualified for a cash rebate.
CEC Rebate program: The State of California provides a cash rebate for qualified purchases of small wind systems, The California Energy Commission (CEC) is offering cash rebates on eligible grid-connected small wind turbine systems through its Emerging Renewables Program (ERP). For more information, please go to
CEC Wind Turbine Rabate
CE certified
1kW Wind Turbine system - SWG FD3.0-1000 with CE certification
SWG FD3.0-1000 system includes 1000w generator, hub, 3 blades, tail, controller, 50 foot cable from generator to controller and nose cone.
Charge Controller is included to convert AC to DC
Recommended wind speed range for 2KW wind turbine is up to 30 mph, if you experience more than 30 mph frequently , higher wind speed or wind gust periodically, please consider H20 or H30 wind turbines for better energy output, reliability and safety.
20-foot guy wire tower is available in "wind turbine towers & kits" category
Can be configured as either off-grid or grid-tie
1KW system is a low Torque, low wind system, rated 1000w at 20 mph, startup wind speed is 4.47 mph.
Battery and inverter are not included, you can purchase batteries and inverters separately from our store.
Batteries Recommended: Four of 200 Amp Hour, 12 Volt Sealed AGM Deep Cycle Battery with LTP Terminal (T975 terminal) - 8A4DLTP-DEKA


New alternator design using most powerful magnets to produce maximum power output at low RPM level. Low start up wind speed at 2 m/s.
Heavy duty design with solid Aluminum housing.
Optional Controller for dump load: Morningstar Tristar TS-45 or TS-60 wind/solar controllers (available in our store)
Morningstar’s TriStar Controller is a three-function controller that provides:
- Charge Control: Constant voltage series PWM design to provide highly efficient battery charging 4-stage charging to increase battery capacity and life: bulk charge, PWM regulation, float and equalizeParallel for larger solar arrays up to 300 amps or more.
- Load Control: Starts large loads including motors and pumps with no damage to controller Allows inrush current to 300 amps Electronic short-circuit and overload protection with automatic reconnect LVD is current compensated and has a delay to avoid false disconnects.
- Diversion Control (Dump load): May be used for solar, wind or hydroelectric. To protect against battery overcharge,excess energy is diverted from primary battery to a secondary battery or alternate DC resistive load. PWM reduces power into diversion load during overcurrent conditions.
Inverter warnings: we don't recommend cheap inverters made in China, because they have serious quality problems and performance is unstable, service life is short on these cheap inverters. They are not UL listed, it won't pass safety inspection. If you are buying these cheap inverters, you run the risk of burning down your house and damage valuable items.
Inverter recommendations: We recommend UL listed inverters made by Xantrex or Outback.
Optional Inverter: Outback or Xantrex Inverters
Click HERE to buy inverter
WindMax Green Energy reserves the right to change or modify any of the products and their inherent physical and technical specifications without prior notice.
WindMax Green Energy and its affiliates assume no responsibility or liability for any errors or inaccuracies within.
WindMax Green Energy will not be liable for any damage or loss suffered by any person arising out of the reliance of any information in this document.
In any claim against us our liability is limited to the value of the goods you have purchased in the contract which is the subject of the dispute.
Call or Email for freight quotes to other countries.
ATTENTION TO COUNTRIES OTHER THAN United States: Shipping charges WILL NOT be added to your final checkout total. We will contact you for shipping charges to your location.
Clearance ! All sales final !
PLEASE ALLOW A 8 WEEKS LEAD TIME
Product Specifications
Technical Specifications:
Voltage: 48v
Alternator: 3-Phase AC permanent magnet PMA
Rated Power Output: 1000w
Max Power Output: 1500w
Rated Speed: 400 RPM
Rated Wind Speed: 9 m/s or 20 mph
Start-up Wind Speed: 2 m/s
Wind Blades: 3 blades per system
Blade Material: Reinforced Fiber Glass
Blade Diameter: 2.7 M (8.9 Feet)
Tower Height: 6 Meters/20 Feet and up depending on siting area
Pipe Size: 4.5" or more Diameter Steel Pipe
Recommended Batteries: 4 of 200AH, 12V AGM or GEL batteries
Applications: refrigerator, washer, water pump, electric cooker, color TV, lighting, electric fan and battery charging.
All technical data is provided by manufacturer. No warranties or guarantees are made, expressed, or implied on information we provided in this document such as performance, power output, etc.
